Bellow Seal Valve

Bellow Seal Globe Valve – Overview

The Bellow Seal Globe Valve from Forxar is engineered for leak-proof shut-off and precise flow regulation in critical applications involving toxic, hazardous, or high-temperature media. As a trusted bellow seal globe valve manufacturer in India, Forxar builds every valve to eliminate stem leakage entirely, using a welded metallic bellows design that seals the stem from the process fluid, A critical safety feature for plants handling flammable, corrosive, or fugitive-emission-regulated media.

Globe valves themselves play a vital role in controlling fluid flow within industrial systems, known for their adaptability and efficiency. Our bellow seal globe valve stands apart from a standard globe valve by adding a secondary, welded barrier around the stem, so even if the packing were to fail, there is zero chance of leakage to atmosphere.

Design & Construction

Our bellow seal globe valve is available in cast and forged construction using Carbon Steel, Stainless Steel, Duplex Stainless Steel, and special MOC for NACE-compliant service. The multi-ply metallic bellows are manufactured in AISI 321, 316Ti, or Inconel 625, tested to a defined cyclic life so you know exactly how long the valve will perform under repeated stem movement.

• Sizes: 1/4″ NB to 24″ NB
• Pressure Class: ANSI Class 150 to 2500 (select sizes)
• End Connections: Screwed, Flanged, and Butt Weld ends
• Bonnet Design: Bolted or Welded bonnet options
• Body Design: Z-type, Angle type, Y-type, and Three-way configurations
• Standards: Designed to API 602 and international norms for critical service valves

Key Features

• Pressure-sealed bonnet for tight, leak-free closure
• Finely machined seats and surfaces for bubble-tight shutoff
• Shorter stroke length than gate valves – faster response, more precise throttling
• Low-torque, quick-opening mechanism for ease of operation
• Zero fugitive emissions – ideal for plants under environmental compliance mandates

Applications of Bellow Seal Globe Valve

Our bellow seal globe valve is built for use across:

• Oil & Gas – precise flow control in upstream, midstream, and downstream processes handling hazardous hydrocarbons
• Chemical Plants – safe handling of toxic and corrosive process media
• Power Stations – steam and boiler feedwater systems requiring reliable, leak-free regulation
• Pharma & Bulk Drug Industry – contamination-free flow control
• Refineries – high-temperature, high-pressure service where stem leakage is not an option
• HVAC Systems – precise regulation of hot water, chilled water, and refrigerant flow

Why Choose Forxar’s Bellow Seal Globe Valve?

As a leading bellow seal globe valve manufacturer and supplier based in India, Forxar combines rigorous quality control with export-ready manufacturing to serve clients across the Middle East, Southeast Asia, and beyond. Every bellow seal globe valve we produce is tested for cyclic bellows life, hydrostatic integrity, and seat tightness before it leaves our facility, ensuring long-term reliability in the most demanding refinery, chemical, and power-plant environments.

Each valve is manufactured to API 602 requirements, with bellows cyclic life independently verified and material certification issued for every batch, giving plant engineers documented proof of quality before installation. Our precision-machined seats and pressure-sealed bonnets are tested for bubble-tight shutoff under real service conditions, ensuring the reliability our clients depend on. This same zero-leakage engineering philosophy runs across our full range. explore our Bellow Seal Gate Valve, Bellow Seal Eurochloro Valve, and Bellow Seal Control Valve for other critical-service applications requiring absolute sealing integrity.

Whether you need a single valve or a bulk order for a new plant build, our team can support you with technical documentation, custom specifications, and fast turnaround. Get in touch for a quote on our bellow seal globe valve range today.
