2 Way Manifold Valve Manufacturer in India – Instrumentation Manifold Valves

Forxar Industries Pvt. Ltd. is a trusted 2 Way Manifold Valve Manufacturer in India, offering precision-engineered instrumentation manifold valves designed for pressure isolation, controlled venting, and safe maintenance of pressure measurement instruments.

A 2-Way Manifold Valve, also known as a 2 Valve Manifold, Double Valve Manifold, or Block and Bleed Manifold, is used in pressure instrumentation systems to control the connection between a process line and a pressure gauge or pressure transmitter.

A typical 2-way manifold incorporates two separate valve functions: one for isolating the process pressure and another for controlled venting or bleeding of pressure from the instrument side.

This compact arrangement allows operators to isolate pressure instruments for inspection, calibration, replacement, and maintenance without unnecessarily disturbing the main process piping.

Forxar 2-Way Manifold Valves are engineered with precision-machined flow passages, suitable sealing components, and carefully selected materials to support reliable pressure control and instrumentation performance.

Our industrial instrumentation manifolds are suitable for oil and gas, petrochemical, chemical processing, power generation, hydraulic systems, and other demanding industrial applications.

Why Choose Forxar – 2 Way Manifold Valve Manufacturer in India?

As an experienced 2 Way Manifold Valve Manufacturer in India, Forxar Industries focuses on engineering quality, dimensional accuracy, reliable sealing, and convenient instrument maintenance.

Key Features and Benefits

1. Reliable Pressure Isolation

The isolation valve allows controlled separation of the pressure instrument from the process line, supporting safe maintenance and calibration procedures when used according to approved operating practices.

2. Integrated Venting Function

The bleed valve provides a controlled venting connection for releasing trapped pressure from the instrument side after proper isolation.

3. Compact Block and Bleed Design

The integrated manifold arrangement combines isolation and venting functions in a compact body, reducing the need for multiple separate instrument valves and fittings.

4. High-Pressure Capability

Selected Forxar 2-Way Manifold Valve configurations are specified for pressures up to 6000 PSI (approximately 414 bar), subject to the applicable material, temperature, seal design, and pressure rating.

5. Precision-Machined Components

Carefully machined valve seats, stems, and internal passages support controlled operation and dependable sealing performance.

6. Material Versatility

Available material options include SS316, SS304, Monel, Hastelloy, and other specified alloys to suit different process environments.

7. Flexible Installation Options

Direct mounting and remote mounting configurations can accommodate different pressure instruments and installation arrangements.

8. Convenient Instrument Maintenance

The block and bleed arrangement facilitates instrument isolation and controlled depressurization before inspection, calibration, or replacement.

2-Way Manifold Valve Technical Specifications

Forxar manufactures and supplies industrial instrumentation manifold valves based on approved drawings, customer specifications, and application requirements.

Body Material Options:

• Stainless Steel SS316
• Stainless Steel SS304
• Monel
• Hastelloy
• Other special alloys on request

Technical specifications:

• Product Type: 2-Way Manifold Valve / 2 Valve Manifold
• Valve Configuration: Isolation and Bleed / Vent
• Maximum Stated Pressure Rating: Up to 6000 PSI (414 bar)
• Stated Temperature Capability: Up to 240°C with specified PTFE-based sealing arrangements and up to 450°C with suitable graphite-based arrangements, subject to complete valve design verification
• Connection Types: NPT / BSP / Socket Weld / Flanged, where applicable
• Connection Sizes: ¼” and ½” Male / Female, according to configuration
• Mounting: Direct or Remote
• Bonnet Type: Screwed / Integral
• Seating Options: Soft Seat or Metal Seat, as specified
• Operation: Manual
• Inspection and Testing: According to approved quality plans and applicable project requirements

Pressure and temperature ratings must be evaluated together. The maximum pressure and maximum temperature listed above should not be assumed to apply simultaneously.

Selection must also consider material compatibility, instrument connection requirements, pressure cycling, sealing arrangements, and operating conditions.

Applicable engineering references may include ASME B31.3 for process piping and ASME B1.20.1 for applicable pipe thread requirements.

For additional technical information, visit the official ASME Codes and Standards website.

How Does a 2-Way Manifold Valve Work?

A 2-Way Manifold Valve typically contains two independently operated valves within a single manifold body.

The first valve acts as an isolation valve, controlling the process pressure connection to the measuring instrument.

The second valve provides a bleed or vent function, allowing controlled release of trapped pressure from the instrument side after the process connection has been isolated.

During normal instrument operation, the isolation valve is generally open and the bleed valve remains closed.

For maintenance, the process connection is isolated first. The instrument side can then be depressurized through the bleed connection using the approved site procedure and a suitable discharge arrangement.

This configuration simplifies pressure instrument maintenance and helps reduce the number of individual components required around the instrument.

However, a two-valve manifold should not automatically be treated as a double-block-and-bleed arrangement. Additional isolation requirements may apply for hazardous services and critical maintenance tasks.

Industrial Applications of 2-Way Manifold Valves

Forxar 2-Way Manifold Valves are used across industrial sectors requiring accurate pressure measurement and controlled instrument isolation.

Oil & Gas Industry

Used in refinery instrumentation, oil and gas processing facilities, and pressure monitoring systems where suitable materials and pressure ratings are specified.

Chemical & Petrochemical Plants

Support pressure transmitter isolation and maintenance in compatible chemical processing applications.

Power Generation Plants

Used in appropriate steam, water, condensate, and auxiliary pressure measurement systems.

Pressure Gauge and Transmitter Isolation

Allow instruments to be isolated from process pressure for inspection, replacement, and calibration when the system has been safely depressurized.

Hydraulic and Pneumatic Systems

Suitable for selected pressure measurement arrangements and test applications requiring controlled isolation and venting.

Offshore and Marine Applications

Available in suitable corrosion-resistant materials for compatible offshore instrumentation systems.

Industrial Test Benches

Used in pressure testing and calibration equipment where controlled pressurization, isolation, and venting are required.

2-Way Manifold Valves and Industrial Valve Solutions from Forxar

As a reliable 2 Way Manifold Valve Manufacturer in India, Forxar Industries also provides engineered valve solutions for process isolation, flow regulation, and critical industrial applications.

Explore our specialized industrial valve products:

• Bellow Seal Gate Valve – Designed for dependable flow isolation and reduced external stem leakage in demanding industrial applications.
• Bellow Seal Globe Valve – Engineered for reliable flow regulation and improved stem sealing performance.
• Bellow Seal Control Valve – Suitable for precise automated process control and flow regulation.
• Bellow Seal Euro Chlor Valve – Specialized valve solutions for suitable chlorine and chlor-alkali processing applications.

Forxar’s instrumentation manifolds and industrial valves support dependable pressure monitoring, fluid control, and process reliability.

Frequently Asked Questions About 2-Way Manifold Valves

What is a 2-Way Manifold Valve?

A 2-Way Manifold Valve is an instrumentation manifold incorporating two separate valve functions, commonly process isolation and controlled venting, within one compact body.

What is the purpose of a 2-Way Manifold Valve?

It is used to isolate pressure measurement instruments from process pressure and provide a controlled means of venting trapped pressure for maintenance or calibration.

What is the difference between a 2-Way and 3-Way Manifold Valve?

A typical 2-Way Manifold Valve is used for single-pressure instrument isolation and venting, while a 3-Way Manifold Valve commonly provides two isolation valves and one equalizing valve for differential pressure instruments.

What is the difference between a 2-Way and 5-Way Manifold Valve?

A typical 2-Way Manifold Valve provides isolation and venting functions for a single pressure instrument. A 5-Way Manifold Valve commonly includes two isolation valves, one equalizing valve, and two vent or test valves for differential pressure transmitter applications.

Are 2-Way Manifold Valves suitable for high-pressure applications?

Yes. Suitable manifold configurations can be designed for high-pressure instrumentation applications when the body material, sealing arrangement, connections, temperature, and pressure rating meet the required specifications.

Which materials are available for 2-Way Manifold Valves?

Typical options include SS316, SS304, Monel, Hastelloy, and other compatible special alloys depending on the process conditions.

Can 2-Way Manifold Valves be used for pressure transmitter calibration?

Yes. They can support isolation and controlled depressurization during instrument calibration procedures. Additional calibration equipment and connections may be required depending on the installation.

How do I select the correct 2-Way Manifold Valve?

Selection depends on operating pressure, temperature, process fluid, instrument type, connection sizes, thread specifications, material compatibility, mounting arrangement, and isolation requirements.

Contact a Trusted 2 Way Manifold Valve Manufacturer in India

Looking for high-quality 2-Way Manifold Valves for industrial pressure instrumentation?

Forxar Industries Pvt. Ltd. offers precision-engineered instrumentation manifold valves and industrial flow-control solutions designed for demanding engineering applications.

Contact our team with your required manifold configuration, material grade, pressure rating, temperature, process fluid, mounting arrangement, and instrument connection specifications for a customized quotation.

Forxar Industries Pvt. Ltd. – Engineering Flow. Delivering Reliability.
